General Information
Manufacturer
Polaris
Model Year
2021
Model
Ranger XP 1000 Waterfowl Edition
Model Code
R21RRB99BZ
Color
Waterfowl Hunt Camo
Brakes/Wheels/Tires
Brakes
Front / Rear – 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking – Park In-Transmission
Wheels
14 in. Black Aluminum
Tires
Front / Rear -29 x 10-14; PRO ARMOR MUD XC
Dimensions
Length
Overall – 120 in. (305 cm)
Height
Overall – 78 in. (198 cm)
Water Fording – Equal to the Seat Base Level
Width
Overall – 62.5 in. (158 cm)
Weight
Dry – 1660.84 lb. (753.34 kg)
GVW – 3,600 lb. (1,632.9 kg)
Ground Clearance
14 in. (35.6 cm)
Wheelbase
81 in. (206 cm)
Turning Radius
13 ft.
Drivetrain
Transmission
Automatic PVT H/L/N/R/P
Drive System
High Performance On-Demand AWD/2WD
Final Drive
Shaft
Electrical
Instrumentation
Gauge – C4
Dual-sweep Analog Dials with 4 in. LCD Rider Information Center – User Selectable Blue / Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet
Lighting
Dual LED Headlamps, 1250lm Low Beam, 2300lm High Beam, Dual LED Taillamps
Engine
Engine
4-Stroke DOHC
Cooling
Liquid
Cylinders
2
Horsepower
82 hp
Displacement
999 cc
Torque
62 lb. ft.
Fuel System
Electronic Fuel Injection
Fuel Tank Capacity
11.5 gal. (43.5 l)
Operational
Front Suspension
Independent, Arched Lower A-arms, 10 in. (25.4 cm) of Travel
Rear Suspension
Independent, Arched Lower A-arms, 10 in. (25.4 cm) of Travel
Steering
Electronic Power – Standard
Tilt Wheel – Standard
Seating
3 person capacity
Adjustable Driver Seat – Standard
Other
Includes
Polaris® PRO HD 4,500 lb. Winch, Arched A-Arms, Premium Cut & Sew Seats, Premium Steering Wheel and Interior Accents, Polaris Pulse Electrical System (6 position), Standard In-Dash SAE Charge Port
Cargo Box Length
36.75 in. (93.3 cm)
Cargo Box Height
12.5 in. (31.75 cm)
Cargo Box Width
54.25 in. (137.8 cm)
Cargo Box
System – Lock & Ride
Load Capacity
Rear Rack – 1,000 lb. (453.6 kg)
Payload – 1,500 lb. (680.4 kg)
Capacity
Total In-Cab Storage – 19.5 gal.
Towing Capacity
2,500 lb. (1,133.9 kg)
Hitch
Standard 2 in. (5 cm) Receiver
